X9556WRS-07-9TV01 2.54mm Wire To Board Connector 07Pin
- Part number
- X9556WRS-07-9TV01
- Category
- XKBproduct
Share your quantity, required date and documentation requirements. Availability and supply conditions are confirmed during quotation.
Request this part ↗Documents & technical information
A verified datasheet is not currently available on this page. Include the exact part number and document requirements in your inquiry.
Ask about documentation →Product information
Overview
The X9556WRS-07-9TV01 is a 07-pin wire to board connector featuring 2.54 pitch. Designed for reliable electrical connections in consumer electronics, industrial equipment, and communication devices.
Details
Reliable Wire Harness Connectivity The X9556WRS-07-9TV01 Wire to Board Connector is suitable for applications where stable wire harness termination and PCB connectivity are required. The 2.54mm pitch layout and 07 contacts support efficient electrical integration. Connection Performance Designed to provide dependable electrical contact, this connector helps maintain signal integrity and connection consistency throughout the service life of the equipment. Connector Specification Featuring a 2.54mm pitch and 07 contact positions, the connector supports compact installation while accommodating various board-level connection requirements. Product specification: 2.54mm 线对板连接器(Molex 70058 2.54小飞机)针座,卧贴,9T料,07P. Recommended Applications - Industrial automation devices - Consumer electronics - Smart equipment - Power control systems - Electronic modules
