XCF32PFSG48C

Xilinx introduces the Platform Flash series of in-system programmable configuration PROMs. Available in 1 to 32 Megabit (Mbit) densities, these PROMs provide an easy-to-use, cost-effective, and reprogrammable method for storing large Xilinx FPGA configuration bitstreams.

Xilinx introduces the Platform Flash series of in-system programmable configuration PROMs. Available in 1 to 32 Megabit (Mbit) densities, these PROMs provide an easy-to-use, cost-effective, and reprogrammable method for storing large Xilinx FPGA configuration bitstreams. The Platform Flash PROM series includes both the 3.3V XCFxxS PROM and the 1.8V XCFxxP PROM. Features • In-System Programmable PROMs for Configuration of Xilinx FPGAs • Low-Power Advanced CMOS NOR FLASH Process • Endurance of 20,000 Program/Erase Cycles • Operation over Full Industrial Temperature Range (–40°C to +85°C) • IEEE Standard 1149.1/1532 Boundary-Scan (JTAG) Support for Programming, Prototyping, and Testing • JTAG Command Initiation of Standard FPGA Configuration • Cascadable for Storing Longer or Multiple Bitstreams • Dedicated Boundary-Scan (JTAG) I/O Power Supply (VCCJ) • I/O Pins Compatible with Voltage Levels Ranging From 1.5V to 3.3V • Design Support Using the Xilinx Alliance ISE and Foundation ISE Series Software Packages • XCF01S/XCF02S/XCF04S - 3.3V supply voltage - Serial FPGA configuration interface (up to 33 MHz) - Available in small-footprint VO20 and VOG20 packages. • XCF08P/XCF16P/XCF32P - 1.8V supply voltage - Serial or parallel FPGA configuration interface (up to 33 MHz) - Available in small-footprint VO48, VOG48, FS48, and FSG48 packages - Design revision technology enables storing and accessing multiple design revisions for configuration - Built-in data decompressor compatible with Xilinx advanced compression technology Hot Tags: xcf32pfsg48c, China xcf32pfsg48c suppliers, manufacturers, diode laser, small outline transistor, rugged embedded pc, field programmable logic device, germanium diode voltage, regulator diode
