UPD4702C
- Part number
- UPD4702C
- Category
- Other Electronic Components
Share your quantity, required date and documentation requirements. Availability and supply conditions are confirmed during quotation.
Request this part ↗Documents & technical information
A verified datasheet is not currently available on this page. Include the exact part number and document requirements in your inquiry.
Ask about documentation →Product information
Overview
The µPD4702 is 8-bit up/down counters for an incremental encoder. Two-phase (A, B) incremental input signals are phase-differentiated, and on each signal edge, an up-count is executed if the A phase is leading, or a down-count if the B phase is leading.
Details
The µPD4702 is 8-bit up/down counters for an incremental encoder. Two-phase (A, B) incremental input signals are phase-differentiated, and on each signal edge, an up-count is executed if the A phase is leading, or a down-count if the B phase is leading. Eight-bit count data is output in real time. A carry output and borrow output are also provided for counter overflow and underflow. The µPD4704 is also available; use of these enables the count width to be extended.
