ADF4372BCCZ

The ADF4372BCCZ is a microwave wideband synthesizer with an integrated voltage-controlled oscillator (VCO), designed by Analog Devices for ultra-low phase noise and high frequency agility.

Key Features Type: Wideband Frequency Synthesizer with Integrated VCO Frequency Range: Fundamental Output: 3.05 GHz – 6.1 GHz Divided Outputs: 62.5 MHz – 16 GHz (via output dividers ×1 to ×64) PLL Type: Fractional-N and Integer-N supported Reference Input Frequency: 10 MHz – 600 MHz Phase Noise: −120 dBc/Hz @ 100 kHz offset (5 GHz output typical) −146 dBc/Hz @ 1 MHz offset RMS Jitter: 38 fs (1 kHz – 100 MHz offset) Spurious Output: < −90 dBc typical Lock Time: < 50 µs (typical) Reference Doubler and Divider: Integrated (×2, ÷1, ÷2) Power Supply Voltages: VCO: 5.0 V (±5%) PLL Core & Digital: 3.3 V (±5%) Current Consumption: 335 mA typical total Output Power: +5 dBm typical (fundamental output) Output Type: Differential (open-collector) Interface: 3-wire SPI programmable Package Type: 48-lead LGA with exposed pad Package Dimensions: 7 mm × 7 mm × 1.1 mm Mounting Style: Surface Mount (SMD) Operating Temperature Range: −40 °C to +105 °C RoHS / REACH: Compliant and Pb-free Performance Highlights Ultra-wide frequency range from 62.5 MHz to 16 GHz Very low phase noise and RMS jitter for precise signal generation Dual-mode operation: fractional-N and integer-N PLL Integrated VCO eliminates need for external oscillators Fast frequency switching (< 50 µs typical) Programmable output dividers for flexible frequency planning Compact 7 × 7 mm package for dense RF/microwave boards Applications Microwave and RF communication systems 5G and wireless base stations Test and measurement equipment Radar and electronic warfare (EW) systems High-speed clock generation Data converter (ADC/DAC) clocking and sampling systems Hot Tags: adf4372bccz, China adf4372bccz suppliers, manufacturers
