5AGXBA5D4F31C5N

The 5AGXBA5D4F31C5N is a member of the Arria V GX family of high-performance, mid-range FPGAs developed by Intel (formerly Altera).

Key Features Device Family: Arria V GX FPGA Type: Mid-range, transceiver-enabled FPGA Logic Elements (LEs): ~190,000 Adaptive Logic Modules (ALMs): ~74,000 Memory: ~13.6 Mbit embedded memory DSP Blocks: 312 variable-precision DSP blocks Transceivers: 12 full-duplex transceiver channels up to 6.5 Gbps I/O Pins: 384 user I/Os PLL Count: 6 PLLs Core Voltage (VCC): 1.1 V typical I/O Standards Supported: 1.2 V – 3.3 V Configuration Modes: JTAG, Active Serial x4, Passive Serial, Fast Passive Parallel Package: 896-FBGA (31 mm × 31 mm, 1.0 mm pitch) Temperature Grade: Commercial (0 °C to +85 °C) Speed Grade: -5 (medium-speed performance) Functional Description The Arria V GX series FPGAs integrate high-speed transceivers, advanced DSP resources, and flexible clock networks within a power-optimized 28 nm process technology. The 5AGXBA5D4F31C5N offers a cost-effective solution for applications requiring high data throughput and reliable logic density, without the power penalty of high-end FPGAs. Applications Data and signal processing systems Communication and networking equipment Broadcast and video infrastructure Test and measurement instruments Industrial and embedded computing Hot Tags: 5agxba5d4f31c5n, China 5agxba5d4f31c5n suppliers, manufacturers, ATF16V8B 15PU DIP20 Programmable Logic Device, chips integrated circuits, EP1C6T144C8N TQFP144 Programmable Logic Device, EPM7032LC44 7 PLCC44 Programmable Logic Device, microcontroller integrated circuit, small scale integration circuit
