WS1111

The WS1111 is a CDMA(Code Division Multiple Access) and AMPS(Advanced Mobile Phone Service) power amplifier module designed for handsets operating in the 824-849MHz bandwidth. The WS1111 is manufactured on an advanced InGaP HBT(Hetero-junction Bipolar Transistor) MMIC(Microwave Monolithic Integrated Circuit) technology offering state-of-the-art reliability, temperature stability and ruggedness.

The WS1111 is a CDMA(Code Division Multiple Access) and AMPS(Advanced Mobile Phone Service) power amplifier module designed for handsets operating in the 824-849MHz bandwidth. The WS1111 is manufactured on an advanced InGaP HBT(Hetero-junction Bipolar Transistor) MMIC(Microwave Monolithic Integrated Circuit) technology offering state-of-the-art reliability, temperature stability and ruggedness. The WS1111 meets stringent CDMA linearity requirements to and beyond 28dBm output power. The 4mmx4mm form factor 10-pin surface mount package is self contained, incorporating 50ohm input and output matching networks. General Features - 2.0um InGaP HBT Technology - Good Linearity - High Efficiency - 10-pin Surface Mounting Package(4mmx4mmx1.4mm) - 50ohm Input and Output Matching - CDMA 95A/B, CDMA2000-1X/EVDO Applications - Digital Cellular(CDMA) - Analog Cellular(AMPS) Hot Tags: ws1111, China ws1111 suppliers, manufacturers, optical transceiver, OP177GPZ Marking OP177 DIP8 Precision Op Amp, monolithic integrated circuit, high frequency diode, solar bypass diode, real diode
